1. Operational Conditions:
Temperature: -20℃ to +120℃
Pressure: ≤1.4MPa
Speed: ≤15m/s

2. Materials:
Stationary Ring: Ceramic (Alumina), Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide, Co-binder Tungsten Carbide
Rotary Ring: Resin Impregnated Carbon Graphite (Furan), Antimony Impreg, Carbon Graphite, Silicon Carbide Sintered Pressureless, Silicon Carbide Reaction Bonded, Co-binder Tungsten Carbide, Ni-binder Tungsten Carbide
Secondary Seal: Nitrile (NBR), Ethylene Propylene (EPDM), Fluorocarbon Rubber (Viton)
Spring and Metal Parts: Stainless Steel, Stainless Steel

3. Applications: Clean Water, Sewage Water, Oil and other moderately corrosive fluids
