Operations Conditions:
Temperature:-40℃ to +250℃
Pressure:≤1.2MPa
Speed:≤15m/s

Materials:
Stationary Ring:Silicon Carbide Reaction Bonded,Ceramic(Alumina),Silicon Carbide Sintered Pressureless
Rotary Ring:Antimony Impreg. Carbon Graphite,Resin Impregnated Carbon Graphite(Furan), Silicon Carbide Reaction Bonded,Silicon Carbide Sintered Pressureless
Secondary Seal:Pure PTFE
Spring and Metal Parts:Stainless Steel,Stainless Steel,Hastelloy C-4 Alloy

Applications：Strong corrosive fluids
